<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
<X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation =' https://www.web3d.org/specifications/x3d-3.3.xsd '>
<head>
<meta name='title' content='HelloX3dAuthorsAnimationChain.x3d'/>
<meta name='creator' content='Don Brutzman'/>
<meta name='created' content='5 October 2000'/>
<meta name='modified' content='20 October 2019'/>
<meta name='description' content='Fully developed animation-chain example showing spinning globe and text: Hello!'/>
<meta name='identifier' content=' https://X3dGraphics.com/examples/X3dForWebAuthors/Chapter07EventAnimationInterpolation/HelloX3dAuthorsAnimationChain.x3d '/>
<meta name='reference' content=' https://www.web3d.org/x3d/content/examples/Basic/course/HelloX3dAuthorsAnimationChain.x3d '/>
<meta name='generator' content='X3D-Edit 3.3, https://savage.nps.edu/X3D-Edit'/>
<meta name='license' content=' ../license.html'/>
</head>
<!--
Index for DEF nodes : ClickTriggerTouchSensor, EarthCoordinateSystem, MiniWorld, OrbitalTimeInterval, SimpleGeoStationarySatellite, SpinThoseThings
Index for Viewpoint image : Viewpoint_1
-->
<Scene>
<WorldInfo info='"an introductory scene"' title='Hello X3D Authors Animation Chain'/>
<Viewpoint description='Hello, world' orientation='0 1 0 3.14159' position='0 0 -8'/>
<!-- change TimeSensor loop='true' to enable automatic animation when loaded, rather than TouchSensor trigger to start -->
<!-- ROUTE information for OrbitalTimeInterval node:  [from ClickTriggerTouchSensor.touchTime to startTime ] [from fraction_changed to SpinThoseThings.set_fraction ] -->
 <TimeSensor DEF='OrbitalTimeInterval' cycleInterval='12'/>
<!-- ROUTE information for SpinThoseThings node:  [from OrbitalTimeInterval.fraction_changed to set_fraction ] [from value_changed to EarthCoordinateSystem.set_rotation ] -->
 <OrientationInterpolator DEF='SpinThoseThings' key='0.00 0.25 0.50 0.75 1.00' keyValue='0 1 0 0 0 1 0 1.57079 0 1 0 3.14159 0 1 0 4.7123889 0 1 0 6.2831852'/>
<ROUTE fromNode='OrbitalTimeInterval' fromField='fraction_changed' toNode='SpinThoseThings' toField='set_fraction'/>
<!-- ROUTE information for EarthCoordinateSystem node:  [from SpinThoseThings.value_changed to set_rotation ] -->
 <Transform DEF='EarthCoordinateSystem'>
<ROUTE fromNode='SpinThoseThings' fromField='value_changed' toNode='EarthCoordinateSystem' toField='set_rotation'/>
<Group DEF='MiniWorld'>
<Shape>
<Appearance>
<ImageTexture
  url=' "../../earth-topo.png" "../../earth-topo.gif" "../../earth-topo-small.gif" "https://X3dGraphics.com/examples/X3dForWebAuthors/earth-topo.png" "https://X3dGraphics.com/examples/X3dForWebAuthors/earth-topo.gif" "https://X3dGraphics.com/examples/X3dForWebAuthors/earth-topo-small.gif" '/>
</Appearance>
<Sphere/>
</Shape>
</Group>
<Transform DEF='SimpleGeoStationarySatellite' rotation='1 0 0 .3' scale='0.1 0.3 0.1' translation='0 0 5'>
<Shape>
<Appearance>
<Material diffuseColor='0.9 0.1 0.1' emissiveColor='0.9 0.2 0.1'/>
</Appearance>
<Text string='"Hello X3D Authors !!"'>
<FontStyle size='3'/>
</Text>
</Shape>
</Transform>
<!-- ROUTE information for ClickTriggerTouchSensor node:  [from touchTime to OrbitalTimeInterval.startTime ] -->
 <TouchSensor DEF='ClickTriggerTouchSensor' description='Click to start animation'/>
<ROUTE fromNode='ClickTriggerTouchSensor' fromField='touchTime' toNode='OrbitalTimeInterval' toField='startTime'/>
</Transform>
</Scene>
</X3D>
<!--
